Rain Bird HE-VAN-15 High-Efficiency Adjustable Spray Nozzles 10-Pack — 12–15 ft, 0°–360° Arc, Click-Stop

Rain Bird HE-VAN-15 nozzles are high-efficiency adjustable spray nozzles that deliver uniform coverage and wind-resistant droplets for 12–15 ft spacing in a convenient 10-pack.

These HE-VAN-15 replacement nozzles are designed to upgrade sprinkler performance, reduce misting, and help eliminate dry spots near the spray head. Built with a tactile click-adjust arc and precision screens included, the 10-pack provides everything needed to tune residential or commercial spray zones. They’re compatible with standard pop-up spray bodies (sprinkler bodies sold separately) and perform best within the specified pressure range for consistent results.

How far will the HE-VAN-15 spray reach and what pressure works best?

The HE-VAN-15 has a throw range intended for 12–15 feet (approximately 3.7–4.6 m). It operates across a 15–30 psi range with an optimum performance point at about 30 psi. Proper pressure at the nozzle ensures designed spacing and droplet size for wind resistance.

• Recommended spacing: 12–15 ft (3.7–4.6 m)
• Operating pressure: 15–30 psi (1.0–2.1 bar)
• Optimum pressure: 30 psi (2.1 bar)
• Use 1800/RD1800 PRS spray bodies to maintain performance at higher pressures

What adjustments can I make to control coverage and prevent drift?

The nozzle offers full adjustability from 0° to 360°, so you can tailor the arc to beds, lawns, and irregular shapes. A tactile click feature locks the arc setting in place, preventing the arc from drifting after installation and helping maintain a consistent watering pattern.

• Adjustable arc: 0°–360° for targeted watering
• Click-stop mechanism secures arc settings
• Screens included to reduce debris-related clogging

Why are these nozzles considered water-efficient and how do they save runtime?

HE-VAN nozzles are engineered to produce larger, wind-resistant droplets that reduce misting and airborne evaporation. By delivering water where it’s needed and lowering evaporation loss, they can reduce zone run times compared with conventional nozzles, helping you stay within tight watering windows.

• Large droplets reduce mist and drift
• Even coverage reduces dry spots and repeat cycles
• Shorter recommended runtimes versus many competitive nozzles

How easy is installation and what’s included in the package?

The pack contains ten HE-VAN-15 nozzles plus screens; sprinkler bodies are not included. Installation is straightforward—remove the old nozzle, insert the screen, and thread the HE-VAN nozzle into a compatible pop-up spray body. No special tools are required for standard retrofits.

• Contents: 10 HE-VAN-15 nozzles and screens
• Sprinkler body: sold separately
• Tool-free arc adjustments and tactile click setting

Who is this for: Landscape professionals, irrigation contractors, and homeowners looking to upgrade spray zones for improved uniformity and reduced water waste will benefit from the Rain Bird HE-VAN-15 10-pack. It’s a practical choice when replacing worn nozzles, tuning irrigation layouts for tighter spacing, or converting existing systems to more wind-resistant, water-conscious spray patterns.
