KAIERSUGT Minn Kota Control Box Cover Kit - Fits All Terrain/Edge/Maxxum (Red & Yellow Arrow), Complete Indicator Assembly

KAIERSUGT Control Box Cover Kit replaces worn or broken Minn Kota foot control housings and restores smooth indicator operation for a precise fit with compatible AT, FC, Edge, and Maxxum models.

This replacement kit gathers the case, indicator assembly parts, screws, and an anti-rattle washer you need to repair the foot control on many Minn Kota trolling motors. It’s engineered to match the original mounting points and arrow-color identification used by Minn Kota so you can choose the correct fit for your year and model. Whether you’re fixing an older All Terrain or updating an Edge foot pedal, the components in this kit simplify a durable restoration without hunting down multiple small parts.

Which Minn Kota foot controls will this cover kit fit?

The kit is compatible with a broad range of Minn Kota foot controls from the mid-1990s through recent Edge models. It covers All Terrain (AT/FC) and many Foot Control (FC) units produced between 1994 and 2008, specific Edge FC ranges, and Maxxum foot controls made up to 2010.

• Fits 1994–2008 All Terrain/AT and foot control models with backward compatibility.
• Fits 2006–2011 Edge FC units identified by the red directional arrow.
• Fits 2012+ Edge FC units identified by the yellow directional arrow.
• Compatible with 1998–2010 Maxxum foot controls.

What parts are included, and will I need extra tools?

The package provides the main control box cover, a matched control box, a full indicator assembly, assorted screws, and an anti-rattle washer so you won’t have to source small components separately. Basic hand tools like a Phillips screwdriver and a small socket or nut driver are usually sufficient for installation.

• Included: control box cover (2260216/2260283/2260286) and control box (2262515).
• Indicator assembly set: gears 2267800, bracket 2261905, decal 2265800, indicator 2260150, drive 2262220.
• Hardware: nine screws (six 2372100, three 2053414) and anti-rattle washer 2261733.
• Recommended tools: Phillips screwdriver and small socket or nut driver.

How do I confirm the correct kit for my pedal — red arrow or yellow arrow?

Identify the directional arrow color on your existing Edge foot control to select the proper fit: older Edge FCs use a red arrow, while later models use a yellow arrow. The kit documentation and part numbers correspond to those color cues so you can match the cover to your pedal’s factory configuration.

• Red arrow: Edge FC models from about 2006–2011.
• Yellow arrow: Edge FC models from 2012 onward.
• If unsure, compare the old cover color marking or cross-check your foot control part number.
• Contact support with photos if fitment remains unclear.

Who is this for: Boat owners and marine technicians who need a complete, OEM-style replacement control box cover and indicator assembly for Minn Kota foot controls. This kit suits anglers restoring older All Terrain, Edge, or Maxxum pedals, DIYers wanting a single-package repair solution, and service shops that prefer stocking a versatile replacement kit matched to common Minn Kota models.
